Drone Batteries
DJI batteries and their specs
DJI Spark
- Battery Specifications: 11.4 V, 1480 mAh
- Recommended Charger: DJI Spark Battery Charger or Charging Hub
- Charging Voltage: 12.6 V
DJI MINI SERIES
DJl Mini (Original)
- Battery Specifications: 7.2V. 2400 mAh
- Charging Voltage: 8.4
- Recommended Charger: DJI 18W USB Charger or Two-Way Charging Hub
Battery Specifications: 7.7 v. 2250 mAh
- Charging Voltage: 8.8 V
- Recommended Charger: DJI 18W USB Charger
DJI Mini 2
- Battery Specifications: 7. 7 v. 2250 mAh
- Recommended Charger: DJI 18W USB Charger or Two-Way Charging Hub
- Charging Voltage: 8.8 v
DJI Mini 3
- Battery Specifications: 7.38 v. 2453 mAh
- Recommended Charger: DJI 30W USB-C Charger or Two-Way Charging Hub
- Charging Voltage: 8.5
DJI Mini 4
- Battery Specifications: 7 .38 v. 3850 mAh
- Recommended Charger: OJI 30W USB-C Charger or Two-Way Charging Hub
- Charging Voltage: 8.5 V
DJI Mini 4 Pro
- Battery Specifications: 7 .38 v. 3850 mAh
- Charging Voltage: 8.5 V
- Recommended Charger: DJI 30W USB-C Charger or Two-Way Charging Hub
DJI Mavic Series
DJI Mavic Pro Platform
- Battery Specifications: 11.4 v. 3830 mAh
- Charging Voltage: 13.05 V recommended DJI Mavic charger
DJI Mavic Air 2
- Battery Specifications: 11.55 v. 3500 mAh
- Recommended Charger: DJI Mavic Air 2 Battery Charger or Charging Hub
- Charging Voltage: 13.2
DJI Air 2S
- Battery Specifications: 11.55 v. 3750 mAh
- Recommended Charger: DJI Air 2S Battery Charger or Charging Hub
- Charging Voltage: 13.2 V
DJI Air 3
- Battery Specifications: 15.4 v. 4480 mAh
- Recommended Charger: DJI 65W Portable Charger or Battery Charging Hub
- Charging Voltage: 17.6 V
DJI Air 3S
- Battery Specifications:
- Capacity: 4240 mAh
- Voltage: 15.4 V
- Type: LiPo 4S
- Charging Parameters:
- Max Charging Voltage: 17.6 V
- Recommended Charger: OJI 65W Portable Charger or Battery Charging Hub
This battery is designed for the DJI Air 3S and uses a higher voltage and capacity compared to previous Air models. Always ensure to use the official charger or compatible alternatives that meet these specifications for safe charging.
DJI FPV Drone Battery
- Battery Specifications:
- Capacity: 2000 mAh
- Voltage: 22.2 V
- Type: LiPo 6S
- Energy: 44.4 Wh
- Discharge Rate: Standard 10C
- Weight: 295 g
- Max Charging Power: 90 W
- Max Charging Voltage: 25.2 V
Additional Notes:
- The DJI FPV Intelligent Flight Battery is designed for use with the DJI FPV drone. providing up to approximately 20 minutes of flight time.
- It features an intelligent battery management system that monitors battery status in real-time for a more worry-free flight.
Here’s the information for the DJI Avata series:
DJI Avata
- Battery Specifications: 11.55 v. 2420 mAh
- Charging Voltage: 13.2 V
- Recommended Charger: OJI Avata Battery Charger or Charging Hub
- Always use OJl’s official chargers or compatible alternatives that meet these specifications to ensure safe charging and optimal battery health.
For more detailed information. please refer to DJl’s official product page:
Below is a consolidated list of DJI Phantom series batteries-including the other models (i.e. Phantom 4 Advanced/Professional and the various Phantom 4 iterations)–With their typical charging parameters, Note that these specs represent the official (or most commonly referenced) values; some aftermarket or upgraded batteries might differ
DJI Phantom 1
- Battery Specifications:
- Nominal Voltage: 11.1 V
- Capacity: 2200 mAh (3S Li Po)
- Charging Parameters:
- FuE Charge Voltage: -12.GV
- Maximum Charging Current: -2.2A(-1C rate)
DJI Phantom 2
- Battery Specifications:
- Nominal Voltage: 11.1 V
- Capacity: 5200 mAh (3S Li Po)
- Charging Parameters:
- FuE Charge Voltage: -12.GV
- Maximum Charging Current: -5.2A(-1C rate)
DJI Phantom 3 Series
(This covers the Standard. Advanced. and Professional models-most share the same official battery specs.)
- Battery Specifications:
- Nominal Voltage: 15.2V
- Capacity: 4480 mAh (4S Li Po)
- Charging Parameters:
- FuE Charge Voltage: -17.4V
- Maximum Charging Current: -4.48A (-1 c rate)
- Note: Although some aftermar1cet -Pro· batteries are sometimes advertised with higher capacity. the official spec for Phantom 3 models is generally 4480 mAh.
DJI Phantom 4 Series
(This includes the original Phantom 4. Phantom 4 Advanced. Phantom 4 Pro. and Phantom 4 Pro V2.0-all using very similar battery packs.)
- Battery Specifications:
- Nominal Voltage: 15.2V
- Capacity: 5870 mAh (4S Li Po)
- Charging Parameters:
- FuE Charge Voltage: -17.4V
- Maximum Charging Current: -5.87 A (-1 c rate)
- Recommended Temperature Range: Typically s0c to 40•c (OJI often recommends a minimum of s0c for optimal charging performance)
- Note: While the various Phantom 4 variants share nearly identical battery specs. internal charging circuitry or smart battery management features may vary slightly from model to model.
Always verify the specific battery markings or accompanying documentation-especially when working with repair or thirdparty charging modules-to ensure the correct charging voltage. current and temperature guidelines are used. These parameters are critical both for safety and for maximizing battery longevity.
General Charging Guidelines:
- Use Official Chargers: To ensure safety and battery longevity, always use DJl’s official chargers or charging hubs designed for your specific drone model.
- Charging Environment: Charge batteries in a cool. dry place away from direct sunlight and flammable materials.
- Post-Flight Charging; Allow batteries to cool down to room temperature before charging them after a flight.
For detailed information on battery maintenance and charging, refer to DJl’s official guidelines.
